Stabisoil 1K
Single-Component, Ultra-Low Viscosity Polyurethane Resin for Soil Stabilization
π§ͺ Product Overview
Stabisoil 1K is a single-component, solvent-free polyurethane injection resin engineered for deep soil stabilization. Its ultra-low viscosity allows for exceptional penetration into fine, silty sands and porous substrates. Upon contact with water, the resin forms a rigid, hydrophobic, and chemically resistant conglomerate with the surrounding soil. It delivers high compressive strength in a short time, with no shrinkage or swelling.
π§ Key Features
β Deep Penetration – Flows easily into microvoids and loose soil layers
π§ Water-Activated Reaction – Creates a stiff, durable mass upon contact with water
βοΈ Adjustable Setting Time – Controlled with catalyst (0.5%–2%)
πͺ High Mechanical Strength – Excellent compressive and flexural properties
π§Ό Solvent-Free & Chemically Resistant – Safe, clean, and long-lasting
π« Non-ADR Classified – Safe to transport under international regulations
π Applications
Soil stabilization in civil and geotechnical projects
Filling large voids in rock, gravel, and sand layers
Pre-injection for tunneling and TBM operations
Curtain grouting and water-sealing
Anchoring in both wet and dry conditions
Formation of soil–resin micropiles
π¦ Packaging & Storage
25 kg plastic canister
Store at 10–30β―°C in a dry, ventilated area
Shelf life: 12 months in original sealed container
Sensitive to moisture—use quickly after opening
β οΈ Health & Safety
Use personal protective equipment (PPE)
Ensure good ventilation during use
Avoid skin or eye contact; do not inhale vapors
Refer to product MSDS before application
π Technical Highlights
Property |
Value / Description |
---|---|
Type |
Single-component polyurethane |
Viscosity at 25β―°C |
< 20 mPa·s |
Density |
~1.12 kg/L |
Compressive Strength |
~12 MPa |
Flexural Strength |
~2 MPa |
Catalyst Ratio |
0.5–2% |
Setting Time (with catalyst) |
30–240 sec (based on % used) |
Final Form |
Stiff, hydrophobic, resin–soil mass |
Stabisoil 1K is your trusted solution for deep, fast, and durable soil reinforcement—ideal for civil infrastructure, tunneling, and foundation protection.
